Pipe Carrier
EBC
Design of pipe carrier system with loader attachment and remote controlled dolly
Pipe Carrier
OHL
Conceptual design and budgetary pricing for system designed to transport and place tunnel liner pipe
Pipe Installation System
Michels/Jay Dee/Coluccio
Complete carrier and placer system for 21,000 lb x 110” diameter x 40’ long pipes
Pipe Carrier
SAK®
Pipe carrier for carrying and placing pipe sections 94.5” in diameter, weighing 20,000 lbs
Pipe Carrier – 55K
SAK®
Carrier for pipes weighing up to 55,000 lbs
Pipe Carrier Positioner
Aecon-McNally
Design and build system for moving pipe carrier in shaft without locomotive
Pipe Carrier – 20K
SAK®
Detailed Design and Supply of pipe carrier for 94” diameter pipe weighing up to 20,000 lbs
Pipe Puller Arm
SAK®
Design of pipe puller arm enabling use on alternative pipe diameter
Pipe Carrier
Traylor/Shea
Low profile transport system carries 2 x 104.5” OD x 50’ long x 42,000 pound steel pipes into tunnel. Runs on rail or remote steerable caster wheels. Includes fail safe rail grabbing emergency brake system.
Pipe Carrier
Frontier Kemper/Shea
Tandem carrier with disc brakes, pipe rotation drives, side shift and lift functions on all dollies
Pipe Handling System
Frontier Kemper/Seymour Capilano
Spreader beam picks pipe off of truck and rotates 90 degrees for installation for lowering down shaft. Then tips horizontal to place on hydraulic lift pedestals
Pipe Installation System
Judlau
Conceptual Design and Budgetary estimate for pipe installation system in 12’ diameter tunnel
Pipe Installation System
Flat Iron Constructors
Conceptual design for complete pipe installation system including and carrier and placer
Pipe Carrier
Michels Tunneling
Joint Venture Project with Mining Equipment, Inc
Pipe Handling System
Aecon
Conceptual design of pipe handling system with pipe carrier and rail passer for 118” lined tunnel
Pipe Carrier
Obayashi
Conceptual design and proposal for pipe carrier with capacity of 24,000 lbs., for installation in a 108” wide x 130” high horseshoe shaped tunnel
Pipe Drive Panel – 32″
Allied Pipeline Technologies
Hydraulically driven roller system squeezes and drives pipe for lining existing tunnels
Pipe Drive Panel – 36″
Allied Pipeline Technologies
Hydraulically driven roller system squeezes and drives pipe for lining existing tunnels
Liner Plate Installation System
Judlau
Conceptual design and estimate for self propelled cart engineered to transport and install tunnel liner plates.
Pipe Carrier
Kiewit/Shea
Conceptual design and estimate for pipe carrier on Rondout project
